Stainless Steel Floor Drying Oven with Digital Control

MODEL:

  • FE50SS /50kg
  • FE100SS/100kg
  • FE150SS/150kg
  • FE200SS/200kg
  • FE250SS/250kg
  • FE300SS/300kg
  • FE400MS/SS(400kgs)
  • FE500MS/SS(500kgs)
  • FE600MS/SS(600kgs)
  • FE1000MS/SS(1000kgs)

Holding temperature : 150ºC
Rebaking temperature : 300ºC-400ºC
(for 2 to 4hrs)

External & Internal Body & Compartment Fully Stainless Steel

Prevent Rusty & Long Run

Specifications

Model FE50SS FE100SS FE150SS FE200SS FE250SS FE300SS FE400SS FE500SS FE600SS FE1000SS
Capacity
Electrode Length		 50kg
457mm electrode		 100kg
457mm electrode		 150kg
457mm electrode		 200kg
457mm electrode		 250kg
457mm electrode		 300kg
457mm electrode		 400kg
457mm electrode		 500kg
457mm electrode		 600kg
457mm electrode		 1000kg
457mm electrode
Temperature
Average stabilized		 60ºC – 400ºC
Digital
Input voltage 240VAC
Electrode size 10”,12”,14”,18”
(254,305,356,457mm)
Heating element 1000watts (2) 2000watts (4) 4000watts 6000watts (8)
Insulation (rockfibre wool) 2” (50mm)
Shelved compartment 4 6 8 10 12 14 20 24 28 –
Inside diameter W x L x H (mm) 480 x 310 x 288 mm 480 x 310 x 386 mm 480 x 310 x 484 mm 480 x 310 x 582 mm 480 x 310 x 680 mm 480 x 310 x 778 mm 590 x 480 x 720mm 690 x 480 x 720mm 790 x 480 x 720mm 910 x 481 x 800mm
Outside diameter W xL x H (mm) 580 x 420 x 541 mm 580 x 420 x 639 mm 580 x 420 x 737 mm 580 x 420 x 835 mm 580 x 420 x 933 mm 580 x 420 x 1031 mm 990 x 735 x 820mm 1090 x 735 x 820mm 1190 x 735 x 820mm 1170 x 585 x 965mm
Nett weight 34 kg 40 kg 47 kg 65 kg 75 kg 85 kg 104kg 116kg 128kg 200kg

[wpforms id=”615″]

Categories: ,

High quality and durable holding, re-baking, and reconditioning electrode oven with a mild steel casing to make a requirement for all certifications of calibration.

Features

  • Removable Shelving for use with flux and wire coils
  • Even-Heat Distribution – rectangle shape distributes beat by convention
  • Heating Element – UL Approval File Note UL1030 (E107991)
  • Colour – safety yellow color ensure high visibility
  • Body –External Mild Steel EG
  • Body –Internal Stainless Steel
  • Drive off moisture and get good welds……
  • Guard against rejects……
  • Eliminate rework……
  • Protect welding profits….

A chimney effect that drives air upward along the center support bar, together with the oven’s rectangle shape and vented shelving, allows for exceptional heat flow patterns.
